Our forged steel low temperature butt welding gate valves are specially engineered for cryogenic applications down to -196°C (-320°F). Featuring extended bonnet design and precision forged construction (ASTM A350 LF2/LF3), these valves ensure reliable performance in LNG, industrial gas, and cryogenic processing systems.
✔ Extended Bonnet – Prevents seat freezing and protects packing
✔ Double Seal Design – Stem sealing backseat for maximum safety
✔ Fire-Safe Construction – API 607 compliant options available
✔ Butt Weld Ends – ASME B16.25 for leak-proof pipeline integration
✔ Low Emission Design – Meeting ISO 15848-1 standards
|
Parameter |
Specification |
|
Body Material |
ASTM A350 LF2 (CS), LF3 (Alloy), A182 F316 (SS) |
|
Pressure Rating |
Class 150 - 900 (ASME B16.34) |
|
Size Range |
½" - 24" (DN15 - DN600) |
|
Temperature Range |
-196°C to 38°C (standard) / up to 80°C (special) |
|
End Connection |
Butt Weld (ASME B16.25) |
|
Seat Material |
PTFE, Graphite, Metal-to-Metal |
|
Stem Material |
SS304, SS316, Monel |
|
Bonnet Design |
Extended (standard 4", 8", 12" options) |
|
Design Standards |
BS 6364, API 600, ASME B16.34 |
|
Testing Standard |
API 598 Cryogenic Testing |
Double Piston Effect (DPE) Seals – For ultra-low leakage
Anti-Static Device – Meets IECEx requirements
Thermal Barrier – Optional insulation jacket
Glandless Design – Available for oxygen service
Cryogenic Testing – Each valve tested at operating temperature
LNG Plants: Liquefaction, storage, regasification
Industrial Gases: Oxygen, nitrogen, argon systems
Chemical Processing: Ethylene, propylene service
Aerospace: Rocket fuel handling
Medical Gas: Ultra-pure gas systems
✅ Proven Cold Performance – BS 6364 compliant
✅ Leak-Tight Guarantee – Double sealing system
✅ Specialized Materials – Impact-tested for cryo service
✅ Global Certifications – PED, ASME, ISO 15848
