Our forged steel self-sealing butt welding globe valves feature innovative pressure-assisted sealing technology that automatically enhances sealing performance as system pressure increases. Engineered for precise flow regulation in critical process systems, these valves combine butt weld ends (ASME B16.25) with premium forged construction (ASTM A105/A182) for superior reliability in high-pressure, high-temperature applications.
✔ Pressure-Activated Sealing – Auto-enhancing stem and seat seals
✔ Zero Emissions Design – Meets ISO 15848-1 fugitive emission standards
✔ Fire-Safe Construction – API 607 compliant options available
✔ Precision Flow Control – Excellent throttling characteristics
✔ Maintenance-Free Operation – Self-compensating wear mechanism
|
Parameter |
Specification |
|
Body Material |
ASTM A105 (CS), A182 F304/F316 (SS), F51 (Duplex) |
|
Pressure Rating |
Class 150 - 2500 (ASME B16.34) |
|
Size Range |
½" - 12" (DN15 - DN300) |
|
Temperature Range |
-196°C to 593°C (full range options) |
|
End Connection |
Butt Weld (ASME B16.25) |
|
Seat Design |
Pressure-energized metal/PTFE composite |
|
Stem Seal System |
Self-energizing graphite/PTFE combination |
|
Flow Characteristic |
Linear/Equal percentage |
|
Design Standards |
API 602, ASME B16.34, BS 1873 |
|
Testing Standard |
API 598 ISO 15848 leakage tests |
Dual-Pressure Activation – Seals energized by both upstream and downstream pressure
Wear Compensation – Automatic adjustment maintains seal integrity
Anti-Binding Design – Precision-guided stem movement
Cryogenic to High-Temp – Special versions for extreme services
Bellows Seal Option – For zero-emission requirements
Oil & Gas: High-pressure pipeline regulation
Power Generation: Critical steam systems
Petrochemical: Severe service processes
Chemical Processing: Corrosive media control
Cryogenic Systems: LNG and industrial gases
✅ Superior Long-Term Performance – Maintains sealing integrity over time
✅ Reduced Lifetime Costs – Eliminates routine maintenance
✅ Enhanced Safety – Fail-safe sealing under all conditions
✅ Custom Engineering – Tailored solutions for special applications
