Parameter
|
Details
|
|
Valve Type
|
Hard Seal Ball Valve
|
|
Size Range
|
1/2" to 24" (DN15 to DN600)
|
|
Pressure Rating
|
Class 150 to Class 2500 (PN16 to PN420)
|
|
Temperature Range
|
-196°C to 600°C (-320°F to 1112°F)
|
|
Body Material
|
Stainless Steel, Carbon Steel, Alloy Steel, Duplex Stainless Steel
|
|
Ball Material
|
Stainless Steel with Hard Coating (e.g., Tungsten Carbide, Chromium Carbide)
|
|
Seat Material
|
Metal-to-Metal (Stainless Steel, Inconel, etc.)
|
|
Connection Type
|
Flanged, Threaded, Welded, Socket Weld
|
|
Operation
|
Manual (Lever, Gear) or Automated (Electric, Pneumatic, Hydraulic Actuator)
|
|
Standards
|
API 6D, API 607, ASME B16.34, ISO 17292, ANSI B16.10
|
|
Leakage Class
|
ANSI Class VI (Zero Leakage)
|
