Forged Steel Butt Welded Y Strainer

Premium forged steel butt welded Y strainers provide superior particle filtration in permanent high-pressure piping systems. Featuring ASME B16.25 butt weld ends and ASTM A105/A182 forged construction, these heavy-duty strainers deliver maximum debris capture while minimizing pressure drop in critical oil & gas, petrochemical, and power generation applications.

✔ Permanent Leak-Proof Connection – Butt weld integrity

✔ High-Pressure Capability – Rated to ASME Class 2500

✔ Optimized Flow Path – 45° Y-design reduces turbulence

✔ Easy Maintenance – Removable screen without pipe cutting

✔ Customizable Filtration – 10-200 mesh screens available

360° Perforated Basket – Maximum filtration area

Blow-Out Proof Design – Secured screen retention

Magnetic Insert – Optional ferrous particle capture

Dual Drain Ports – For complete debris removal

High-Velocity Design – Reduced particle embedding

Screen Size&nbspFlow Capacity&nbspPressure Drop

20 mesh (0.85mm)&nbsp100% Cv&nbsp0.2 bar

40 mesh (0.42mm)&nbsp85% Cv&nbsp0.5 bar

100 mesh (0.15mm)&nbsp60% Cv&nbsp1.2 bar

200 mesh (0.075mm)&nbsp40% Cv&nbsp2.5 bar

Pipeline Systems – Pump protection, meter runs

Turbine Inlets – Steam/water particle removal

Compressor Stations – Gas stream filtration

Chemical Injection – Nozzle protection

Marine/Shipbuilding – Fuel oil filtration

• NACE MR0175 compliance
• Jacketed heating models
• Differential pressure gauges
• High-capacity basket designs

✅ 50% Longer Screen Life – Reinforced basket design

✅ Zero-Leak Guarantee – Permanent welded joints

✅ Material Flexibility – Carbon steel to nickel alloys

✅ Global Certifications – ASME, PED, DNV, ABS
