Our forged steel butt welded globe valves are engineered for precise flow regulation in high-pressure, high-temperature systems. Manufactured from premium forged steel (ASTM A105, A182 F304/F316, etc.), these valves offer superior durability and leak-tight performance in critical applications across oil & gas, power generation, and chemical processing industries.
✔ Precision Flow Control - Excellent throttling capability with linear motion stem
✔ Forged Construction - Superior strength compared to cast alternatives
✔ Butt Weld Ends - Permanent, leak-proof connection (ASME B16.25 compliant)
✔ Fire-Safe Design - API 607 compliant options available
✔ Multiple Disc Options - Plug, needle, or composition disc for different applications
✔ Extended Service Life - Hard-faced seats and stems for wear resistance
|
Parameter |
Specification |
|
Body Material |
ASTM A105 (Carbon Steel), A182 F304/F316 (Stainless Steel), F51 (Duplex) |
|
Pressure Rating |
Class 150 - 2500 (ASME B16.34) |
|
Size Range |
½" - 12" (DN15 - DN300) |
|
Temperature Range |
-196°C to 593°C (cryogenic to high-temp versions) |
|
End Connection |
Butt Weld (ASME B16.25) |
|
Trim Materials |
13% Cr, Stellite 6, Tungsten Carbide |
|
Stem Design |
Rising Stem, Non-Rotating |
|
Seat Design |
Integral, removable, or replaceable |
|
Operation |
Handwheel, Gear Operator, Actuated |
|
Standards |
API 602, ASME B16.34, BS 1873 |
|
Testing |
API 598 (100% pressure tested) |
Y-Pattern Body - Reduced pressure drop and turbulence
Metal-to-Metal Sealing - Suitable for high-temperature service
Blowout-Proof Stem - Enhanced safety in high-pressure applications
Anti-Static Device - Standard on all sizes
ISO 5211 Mounting Pad - Ready for actuator installation
Typical Applications
Oil & Gas: Pipeline regulation, wellhead control
Electric/pneumatic actuators
Gear operators
Limit switches
Extended bonnets for cryogenic service
NACE MR0175 compliant materials for sour service
✅ Superior Flow Control - Precise regulation with minimal cavitation
✅ Extended Maintenance Cycles - Hardened trim for long service life
✅ Custom Configurations - Special materials, extended bonnets, bellows seals
✅ Global Certifications - API, ASME, PED, ISO compliant
✅ 24/7 Technical Support - Expert engineering assistance available
